D810
A device for optical inspection of two different PCbas simultaneously with double conveyor and single detector design and a multifunctional mode with adjustable rails.
Double Conveyor On-Line AOI
Flexible/Multi-function AOI
A device for optical inspection of two different PCbas simultaneously with double conveyor and single detector design and a multifunctional mode with adjustable rails.
AOISmart Double Conveyor AOI
The same series multi-configuration apply for different requests
The professional character recognition function (OCR/OCV)，further enhance the testing precision
Double conveyor design
The first conveyor is fixed, the second and the third conveyors are automatically adjustable,the fourth conveyor can adjust manually,The maximum width of the 1-4 Conveyor is 686mm
The double conveyor PCB Size :50×50mm~510×300mm
The Single conveyor PCB Size :50×50mm~510×586mm
Database sharing and statistical functions
All internal AOI are managed via central server, all single machines are in remote control. SPC reports will be generated through collection and analysis of all data to promote process improvement and improve products passing rate.
Detailed SPC Analysis Report
To generate a variety of visual reports through analysis and statistics from testing results of all products.
Consumer protection service items usually include "free warranty maintenance",
"regular return visit", "on-site training", "24-hour appeal response" and other
categories. We provide customers with the best equipment and perfect fast
service guarantee with the most sincere attitude.
● The equipment shall be guaranteed free of charge for one year and maintained
for life from the date of acceptance. The operationcontrol software of the sold
equipment shall be upgraded free of charge for life to ensure the latest software
version and optimization of functions.
● Call back and visit customers irregularly, communicate with customers in time
and improve relevant problems.
● The Customer Service Department shall respond to customer demands within
24 hours and within 2 hours after receiving them.
Overseas customers can provide nearby technical services or provide remote
training and technical support according to actual needs.
